Filter product examples by application, technology platform, layer count and surface finish. Open an example to see its specifications.

Product Cases

Product examples

Examples are taken from our company profiles, and specifications are representative values. Designs can be adjusted to your needs; please get in touch.

Memory Modules

Optical & High-Speed Interconnect

  • 800G AEC active electrical cable board (10L any-layer): 10L ELIC · ENIG. 800G active electrical cable board with 10-layer any-layer interconnect and 5 blind via fills.
  • 1.6T AEC active electrical cable board (14L 4-step HDI): 14L · ENIG. 1.6T active electrical cable board in 4-step HDI, with resin plugging on both outer and inner signal layers.
  • 800G AOC active optical cable board (10L any-layer): 10L ELIC · ENEPIG. 10-layer any-layer with controlled-depth drilling, controlled-depth routing and cavities.
  • 800G/1.6T optical module mSAP board (14L 6-step HDI): 14L mSAP · 25/36 µm · ENEPIG. mSAP fine lines with 147 µm BGA pitch; a cavity design with 30/30 µm lines and 130 µm BGA pitch is also available.
  • 3.2T NPO optical module: 3.2T NPO · mSAP. A 3.2T NPO module PCB built with mSAP. NPO (near-packaged optics) places the optical engine close to the switch chip and is the transition stage from conventional pluggable modules to co-packaged optics (CPO). By shortening the electrical interconnect, it lowers PCB insertion loss and reduces DSP compensation power, cutting power consumption by 30%–50% compared with conventional pluggable modules and greatly improving signal integrity (SI).

Server, AI & Networking

Solid-State Drives (SSD)

Consumer & Camera Modules

Capability

Can’t find the same specification?

These examples are only part of what we make. We can evaluate stack-up, materials and impedance design for your application; see Capabilities for our full process capabilities and 2026–2027 technology roadmap.
